The basic public address mixer amplifiers have power ratings from 30W, 60W, 120W, 240W, 350W, 500W to 650W. They are featured of 3 microphone inputs, 2 aux inputs and 2 EMC inputs.

Priority muting is achieved via EMC1-2 for overriding other inputs except Mic1 on front panel. Individual gain controls are provided for Mic 1-3 and Aux 1-2, bass and treble controls and master volume control are provided for overall tone control. 70V, 100V and low impedance 4-16ohms speaker outputs are provided. Extensive protection from short-circuit, overload and high temp.

Features
* Mixer amplifier for paging and background music system
* Rated power from 30W, 60W, 120W, 240W, 350W, 500W to 650W
* 2U rack mount (less than 350W) and 3U rack mount design
* 70V, 100V and low impedance 4-16ohm speaker output
* Three Mic inputs by phone jack type
* Mic 1 with VOX priority and VOX level on front panel
* Mic 2-3 by phone jack on rear panel
* Two Aux Inputs and 2 line inputs for spare use
* Two EMC priority inputs
* EMC1 has priority over all inputs except MIC1
* Mic 1-3, Aux 1-2 and master volume controls and bass/treble tone control
* Short circuit, overload and high temp protection

Optional
* DC 24V available on less than 500W models
* Panel with/without handhold
* Faults monitoring module, it can output short circuit signal to achieve main/spare amplifier switch
Specifications

Model
T-30
T-60
T-120
T-240
Rated Power Output
30W
60W
120W
240W
Speaker Outputs
70V, 100V & 4~16Ω
Input Sensitivity & Impedance
MIC 1, 2, 3: 5mV/600Ω, Unbalanced phone jack input

MIC 2, 3: 775mV/10KΩ, Unbalanced RCA input

AUX 1, 2: 350mV/10KΩ, Unbalanced RCA input

EMC: 775mV/10KΩ, Unbalanced RCA input
Output Sensitivity & Impedance
MIX OUT: 1000mV/470Ω, Unbalanced RCA output
Tone
Bass:±10dB at 100Hz

Treble:±10dB at 10KHz
Frequency Response
50Hz~16KHz(+1dB, -3dB)
S/N Ratio
MIC 1, 2, 3: 66dB; AUX 1, 2: 80dB
THD
Less than 0.5% at 1KHz, 1/3 rated power
Muting Function
MIC 1 overrides other input signals

with 0-30 dB attenuation
Crosstalk
≤50dB
Cooling
Fan automatically start up when temp reaches 55℃
Protection
High temp, overload & short-circuit
Power Supply
~110V/60Hz or ~230V/50Hz or DC 24V
Power Consumption
60W
100 W
200 W
400 W
Weight
6.7Kg
7.1Kg
9.3Kg
16.6Kg
Dimensions
484x335x88mm
484x385x88mm
Finish
Panel: aluminum plate, black
Case: steel plate, black
